Harman/Kardon

AVR 1510S

Details
Variations

375-watt, 5.1-channel, networked audio/video receiver

Promotions
Free Ground Shipping on this Item
Product Actions

This item is currently not available.

Lighter box. Bigger sound

This 375-watt, high-performance, 5.1-channel A/V receiver makes your music, movies and shows sound better than ever. Whether it’s your Blu-ray™ player, HD cable set-top box or game console, you want the best picture quality and sound. And you need one simple way to connect them all. The Harman Kardon® AVR 1510S is a 5.1-channel, networked audio/video receiver that provides you with four 3D-ready HDMI® inputs with 4K pass-through. Plug them in once, and you’re all set. With built-in Spotify Connect feature, you can stream directly Music from your Spotify premium account on your phone, tablet or computer on the same network, and built-in vTuner™ Internet radio connects you to a whole world of online audio entertainment. Versatile and muscular, the AVR 1510S can pump out up to 375 watts; with it, you’ll hear powerful audio with all the clarity you’ve come to love from Harman Kardon products. The receiver is lighter, too, thanks to HARMAN GreenEdge™ certification. You’ll experience serious power, only now in an environmentally friendly form factor. And if you’re one of those who enjoy even more control, the Harman Kardon Remote app is available for download – giving you the freedom to control your home theater experience from the comfort of your own device. Sleek, light and powerful, the Harman Kardon AVR 1510S is the perfect balance between versatility and beautiful sound.

Item# AVR 1510S

General Specifications

Stereo Power 75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
Multichannel Power 75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
High Instantaneous Current Capability (HCC) ±25 amps
Transient Intermodulation Distortion (TIM) Unmeasurable
Slew Rate 40V/sec
Power Requirement 120V AC / 60Hz
Power Consumption <0.5W (standby); 410W maximum

Audio Specifications

Input Sensitivity/Impedance 250mV/27k ohms
Signal-to-Noise Ratio (IHF-A) 75dB
Frequency Response (@ 1W) 10Hz – 130kHz (+0dB/–3dB)

Dimensions

Height 4-3/4" (121mm)
Width 17-5/16" (440mm)
Depth 11-13/16" (300mm)
Weight 10 lb (4.6kg)

AM Tuner

Frequency Range 522kHz – 1,620kHz
Signal-to-Noise Ratio 38dB
Usable Sensitivity (loop) 375μV
Distortion (1kHz, 50% mod) 1.0%
Selectivity (±10kHz) 30dB

FM Tuner

Frequency Range 87.5MHz – 108.0MHz
Usable Sensitivity IHF 1.3μV/13.2dBf
Signal-to-Noise Ratio (mono/stereo) 70dB/68dB
Distortion (mono/stereo) 0.2%/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity (±400kHz) 70dB
Image Rejection 80dB
IF Rejection 80dB

Video Specifications

Television format NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response (Composite Video) 10Hz – 8MHz (–3dB)
HDMI Supports up to 4K x 2K
Click here for a complete list of all specs for this product

Spec Sheet

English 1 MB
  • 1 Harman Kardon AVR 1510S A/V receiver
  • 1 programmable remote control
  • 1 AM loop antenna with 2' (0.6m) cable
  • 1 FM antenna with 6' (1.8m) cable
  • 2 AAA batteries
  • 1 6' (1.8m) AC power cord
  • Quick-start guide
  • Warranty card
  • Safety sheet

The latest owner's manuals, quick start guides, and documents.

{"searchRecords":[{"attributes":{"type":"FAQ__kav","url":"/services/data/v43.0/sobjects/FAQ__kav/ka01Y00000041pfQAA"},"Title":"What HDCP version is featured in the AVR and BDS models?","Id":"ka01Y00000041pfQAA","ArticleNumber":"000005484","ArticleType":"FAQ__kav","Question__c":"What HDCP version is featured in the AVR and BDS models?","Answer__c":"All AVR models up to and including 151S, 161S and 171S feature HDCP version 1.4.\r\n(High-bandwidth Digital Content Protection).\r\nThis is also true for BDS 280, 580, 280S and 580S.\r\n\r\nIt is not possible to update to version 2.2 with any software/firmware update, as this requires a hardware change.\r\n\r\nFuture models may feature version 2.2, made for UHD/4k content."}]}

2 Years Electronics

Products purchased online or from an authorized local retailer and under warranty may qualify for an exchange with a valid receipt.

Purchases made from an unauthorized dealer will not be eligible for exchange.

Call us: 1.800.336.4525

  • Sales and pre-sale assistance
  • Technical help
  • Parts and accessories
AVR 1510S is rated 3.9 out of 5 by 18.
Rated 5 out of 5 by from Fantastic sound and a great price Bought this for my son for Christmas. Sounds fantastic!!! I will be purchasing another one for myself.
Date published: 2019-01-07
Rated 5 out of 5 by from True High Fidelity at a great sale price This replaced a Sherwood stereo receiver and the sound difference was immediately noticeable, Harman Kardon has a much wider frequency response.
Date published: 2018-12-28
Rated 5 out of 5 by from Easy set up Had to replace older model that died. New one easier to set up. Great sound and super surround.
Date published: 2018-12-20
Rated 5 out of 5 by from Sounds Great! Bought this at an unbelievably great price. The unit sounds unbelievable. HK lived up to their reputation for high quality. Customer support is top notch.
Date published: 2018-05-09
Rated 5 out of 5 by from Can't beat quality This is the third receiver that I have gotten from Harman Kardon and just like the others, very easy to set up and enjoying my surround sound
Date published: 2018-03-12
  • y_2019, m_6, d_18, h_23
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_18
  • loc_en_US, sid_avr1510s_, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_harmankardon

Is there a way to use the auto power feature to put the unit to sleep after a predetermined time but NOT completely power the unit off? In other words I would like the unit to sleep automatically but, don't want it to power completely off automatically.

Asked by: Marbieskarb
Hi, the auto power off feature can be changed so it can actually put the HK AVR 1510s to sleep after a predetermined amount(depends on what cable is being used). You can change it under the Master menu and selecting system setup and changing the Auto Power Off settings to off.
Answered by: Mario at Customer Service
Date published: 2019-05-20

I've purchased an Ultra HD HDR TV. Will my AVR 1015s passthrough Ultra HD HDR data? I have an Amazon Fire TV streaming box that supports Ultra HD and I recently upgraded my Netflix account to Ultra HD. Do I need to upgrade cables? Thanks!

Asked by: bakerja999
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer Service
Date published: 2019-02-02

Could this AV receiver handle 3 ohm-rated speakers (1 left, 1 right, and 1 center) in a stereo configuration?

Asked by: arjun403
Hello! Yes, you could connect a 3 ohm speaker to the AVR 1510S.
Answered by: Nick F
Date published: 2019-01-11

I'm wanting to buy this amp for my HKTS system. However, i have read there has been a problem with only allowing the system to run for 90 minutes before it shuts off, unless you change it in the settings everytime you turn it on. Has this been fixed?

Asked by: iwannab3
We would like to work with you directly. Please submit a case request at https://www.harmankardon.com/support-contact.html and the Customer Service Team will be more than happy to assist you
Answered by: Rhae
Date published: 2019-01-04

will the AVR-1510S connect to WiFi to tune in to radio signals without being physically plugged into the network like my laptop or phone?

Asked by: CUarch73
No, the AVR 1510S does not have Wi-fi capability, it would only be able to use the Spotify service when it's connected to the router via ethernet cable.
Answered by: Rhae
Date published: 2019-01-03

Can I hook up my turntable to your receiver and play my records?

Asked by: Chuck101
The AVR 1510s doesn't have a phono preamp for turntables, you'll need to get an external phono preamp in order to get it connected with this receiver and play your records.Although if your turntable already has a built in phono preamp, you may directly connect it to the receiver.
Answered by: Mario at Customer Service
Date published: 2018-12-30

If a record player has an analog out jack, can it be connected to the analog in of the receiver and work?

Asked by: Michael A
Hi! The AVR 1510S does not have a phono input where the record player should be connected.&nbsp;However, if your&nbsp;turntable has a built-in phono preamp, you connect your turntable to one of the receiver's line (or auxiliary) inputs instead of its phono input.
Answered by: Nick F
Date published: 2018-12-19

How long of an HDMI cable from the unit to the TV can be used and will the sound still sink with the TV picture?

Asked by: Notthelatest
Thank you for your question. The length of an HDMI cable does not influence the connection. The only important aspect when it comes to syncing is that the cable is ARC (Audio Return Channel) and that this function is enabled on the TV as well. Should you wish to receive further support, you may contact the Harman Customer Support team by telephone, email or chat in order to receive direct assistance. Please see https://uk.harmanaudio.com/support-contact.html#ns for further details.&nbsp; Thank you.
Answered by: Simon v
Date published: 2018-12-19
