Wireless Bluetooth Streaming
Stream music wirelessly via Bluetooth to enjoy room-filling sound. Connect up to 2 smart devices at the same time and take turns playing music.
8 hours of playtime
The rechargeable battery supports up to 8 hours of playtime
HK Connect+
Amplify your listening experience by wirelessly connecting more than 100 HK Connect+ enabled speakers.
Built-in Microphone Conferencing System
Noise and echo cancellation enables crystal-clear conferencing.
Voice Integration
Access Siri or Google Now from the speaker with a simple button press. This can be easily configured via the HK Connect App.
Premium Materials
The superior fabric and finishing combines with iconic design to compliment any style.
Elegant design full of features and superior sound
Providing the perfect balance of great sound, iconic design, and premium materials, the Onyx Studio 4 is the epitome of room-filling audio. Crafted to be the best sounding, full featured, portable Bluetooth speaker in its class, the Onyx Studio 4 offers two device connections, 8 hours of playtime and Harman Kardon Connect+, which allows you to connect 100+ speakers with the same feature with the touch of a button. Rounding out the Onyx Studio 4 offerings is a built-in microphone with Voicelogic, echo and noise cancellation for crystal-clear conferencing over the speaker.
Item#
HKOS4WHTAM
General Specifications
Support
A2DP 1.3, AVRCP 1.6, HFP 1.6
Transducers
Woofer 2 x 75mm, Tweeter 2 x 20mm
Rated Power
4 x 15W (AC mode); 4 x 7.5W (Battery mode)
Frequency response
50Hz - 20kHz (-6dB)
Signal to noise ratio
80dB A-weighted
Weight: 2061g
Yes
Dimensions
Dimension (H x W x D): 260mm x 278mm x 159.5mm
Yes
Control and Connection Specifications
Bluetooth version: 4.2
Yes
Bluetooth transmitter power
0 - 9dBm
Bluetooth transmitter frequency range
2402MHz - 2480MHz
Bluetooth transmitter modulation
GFSK, π/4 DQPSK, 8DPSK
Battery
Power supply
19V/2A
Battery type
3.7V/3000mAh Lithium-ion
Battery charge time
5 hours
Music playtime
up to 8 hours (Varies by volume level and music content)
Click here for a complete list of all specs for this product
Spec Sheet (EN)
English 709 KB- 1 x Harman Kardon Onyx Studio 4
- 1 x Power adaptor
- 1 x Quick start guide
- 1 x Safety sheet
- 1 x Warranty card
The latest owner's manuals, quick start guides, and documents.
{"searchRecords":[{"attributes":{"type":"FAQ__kav","url":"/services/data/v43.0/sobjects/FAQ__kav/ka01Y000000gErQQAU"},"Title":"Can I take calls from the Onyx Studio 4?","Id":"ka01Y000000gErQQAU","ArticleNumber":"000007465","ArticleType":"FAQ__kav","Question__c":"Can I take calls from the Onyx Studio 4?","Answer__c":"Yes, you can take can incoming call from the Onyx 4 by pressing the call button located between the power button and volume + button."},{"attributes":{"type":"FAQ__kav","url":"/services/data/v43.0/sobjects/FAQ__kav/ka01Y000000gErLQAU"},"Title":"How do I power on and pair the Onyx Studio 4?","Id":"ka01Y000000gErLQAU","ArticleNumber":"000007464","ArticleType":"FAQ__kav","Question__c":"How do I power on and pair the Onyx Studio 4?","Answer__c":"Make sure that the unit you are attempting to connect to is in pairing mode under Bluetooth Settings. Press the power button located on far right outer rim of the speaker. If this is the first time connecting the unit, it will immediately go into pairing mode. HK Onyx 4 Studio should show up on your discoverable devices within 3-5 seconds. Once you choose the HK Onyx Studio 4 on your device, you will be connected and ready to experience that superior Harman Kardon sound."},{"attributes":{"type":"FAQ__kav","url":"/services/data/v43.0/sobjects/FAQ__kav/ka01Y000000gErVQAU"},"Title":"How do I use the HK Connect feature on the Onyx Studio 4?","Id":"ka01Y000000gErVQAU","ArticleNumber":"000007466","ArticleType":"FAQ__kav","Question__c":"How do I use the HK Connect feature on the Onyx Studio 4?","Answer__c":"Download the HK Connect app to your mobile device. Make sure that the Onyx Studio 4 speaker is connected successfully to your mobile device. The HK Connect app should recognize the Onyx Studio 4 within the first few seconds. Once inside the app you can activate the voice assistant and connect to other Connect+ Harman Kardon devices."}]}
1 Year
Products purchased online or from an authorized local retailer and under warranty may qualify for an exchange with a valid receipt.
Purchases made from an unauthorized dealer will not be eligible for exchange.
Call us: 1.800.336.4525
- Sales and pre-sale assistance
- Technical help
- Parts and accessories
Harman Kardon Onyx Studio 4 is rated
out of
5 by
214.
Rated 5 out of
5
by
Skunkie01 from
Room filling sound
Received this as a gift, very impressed with the sound quality, it fills the room with a rich smooth sound
Date published: 2019-06-14
Rated 5 out of
5
by
Chaz25 from
Awesome sound!
The sound produced by this speaker is fantastic. I'm really pleased with myI purchase. My only gripe is that I purchased this speaker in a white finish and it was supplied with a black power pack and lead. Not great!
Date published: 2019-06-11
Rated 5 out of
5
by
Mate from
Geat price/value ratio
I ordered one for trial, one day later I received it and tried to connect with a second one from a friend.
Excelent amazing sound, easy connectivity, so immeniatly I ordered a second one.
Date published: 2019-06-03
Rated 5 out of
5
by
JAB327 from
GREAT PRODUCT
THIS IS MY SECOND ONYX 4 AND THE REASON IT'S A SECOND IS SO I CAN PLAY THEM IN STEREO AND THEY SOUND GREAT!!
Date published: 2019-05-28
Rated 5 out of
5
by
Toni North from
Love My Onyx 4 Studio
This is my three one. I purchased one for me and my grandson a few years ago. I damaged mine this past September by dropping it. Just purchased a new a few weeks ago and I’m treating it like a newborn baby!
Date published: 2019-05-15
Hi, is it posible to connect 2 onyx studio 4 to a TV using a dual minijack cable to rca in stereo mode?
Hi there, I understand you want to connect 2 of your Onyx studio 4 to your TV, doing the dual mini jack cable won't make the sound output a stereo sound. If you need further help, please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-06-11
my onyx 4 wont come on i left it on charger all night and it still wont power on
Hi there, we're here to help with your power issues. If you've left it overnight and still haven't powered it up, then we'll need to check on our options. Please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-06-10
On bluetooth, when I select : "Speakers (HK Onyx Studio 4 stereo)" > the pairing is faulty, always on and off. When I select "Headset Earphone (HK Hands-Free) > pairing is correct for minutes and disconnect. Speaker removed and reconnect many times
Hi, please try to see if pairing the HK Onyx studio 4 to other phones/ tablets does the same thing. If it does, please try to reset the Onyx Studio 4 by pressing and holding the Vol + and the Phone button at the same time until the unit powers off. Don't forget to remove the device from your phones's bluetooth list before you pair again. If it still occurs, please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-05-12
hi mine only plays in mono when using the aux input. is there something wrong?
We would like to get more information to help you out, please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-05-10
I've had my studio for about a year don't play it a lot now when I try to charge it the blanks red 5 * 2 times fast 3 * 2 times fast 556 hours still no charge
We would like to get more information to help you out, have you tried to use a different charger? Please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-05-10
How come my speakers cuts in and out? Could it be because it's low on battery?
It's possible that your speaker is far from your source/phone. Please try to put the device near the HK Onyx studio 4 and see if that helps, otherwise please submit a case request and so we can assist you: https://www.harmankardon.com/support-contact.html
Date published: 2019-05-04
Can you pair the studio 4 with the HK soundbar?
Thanks for reaching out, the Onyx Studio 4 Connect + feature can only be connected to the same exact speaker model. If you have other question or inquiries, please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Date published: 2019-03-25
Can you use HK Remote App with this speaker? I have it hooked up to my record player and I want to be able to remotely control my volume.
Unfortunately the HK Remote app doesn't work with the Onyx Studio 4 as the app only works with certain HK receivers. Thank you.
Date published: 2019-03-25
