Harman Kardon Citation Bar

Details
Variations

The smartest soundbar for movies and music

$1,199.951199.95 each
Promotions
Free Ground Shipping on this Item
Product Actions
Add to cart options

In stock and ready to ship

Order within 21 hrs 00 mins with Free Ground Shipping and receive by Fri, Oct 18
Your zip code 20149 edit | Want it faster?
Beautiful Sound That Speaks To You

The Harman Kardon Citation Bar is a next generation smart soundbar for movies and music. Easy to use with its full-color LCD touch screen, Citation Bar blends innovation in home audio with attention to detail in design, allowing for sophisticated looks and superb bass without a subwoofer. Music lovers will love access to over 300 music services and high-definition streaming through Chromecast built-in, while movie lovers enjoy their all wireless 5.1 home theater system with Citation Surround and Citation Sub. The Google Assistant brings convenient voice control to your Citation Bar when listening to music for hands-free help around the home. Get answers, play music, organize your day, control your smart home, enjoy your entertainment and more, just with your voice!

Item# HKCITATIONBARBLKAM

General Specifications

Model Name Citation Bar
Power Supply 100-240V~50/60Hz
Power consumption in sleep mode <2.0 Watts
Wireless network 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range 2412 – 2472MHz (2.4GHzISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power <20dBm
2.4G Wi-Fi modulation DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi transmitter power <23dBm
5G Wi-Fi modulation QPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi transmitter frequency range 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
Note CITATION BAR is intended to be used for streaming music. A consumer can stream Bluetooth audio to the speaker. A consumer can connect their speaker to the localWi-Fi Network and stream music with Google Chromecast. In addition, the speaker will work with Google Home. This product is designed to be instantly on and ready to play music at a moment's notice, therefore, the Bluetooth andWi-Fi connection must remain active at all times to ensure proper operation. CITATION BAR is in compliance with the European Union energy legislation. CITATION BAR will enter into sleep mode (networked standby) after 20 minutes without operation, after which it can be re-activated via Bluetooth or Wi-Fi.

Audio Specifications

Signal-to-noise ratio >80dB
Output power 150W RMS
Transducer 3 x 20mm tweeter, 6 x (100 x 50) racetrack woofer

Dimensions

Dimensions (W x H x D) 1150 x 64 x 115mm (45” x 2.4” x 4.5”)
Weight 4.1kg (9lb)

Control and Connection Specifications

Bluetooth® version 4.3
Bluetooth transmitter frequency range 2402 – 2480MHz
Bluetooth transmitter power <10dBm
Bluetooth transmitter modulation GFSK,π/4 DQPSK, 8DPSK
Click here for a complete list of all specs for this product

Spec Sheet (EN)

English 477 KB
  • 1 x Citation Bar
  • 1 x Quick-start guide
  • 1 x Warranty sheet
  • 1 x Safety sheet
  • 1 x power cable (1.8m)
{"searchRecords":[{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVLaQAO"},"Title":"HK Citation: Recording conversation","Id":"ka21Y000000SVLaQAO","ArticleNumber":"000008776","Question__c":"Does the Citation speaker record all my conversations?","Answer__c":"No, the Citation speaker does not store any conversations, it listens only for a few seconds and then deletes the file. Only when using \"OK, Google\" or \"Hey, Google\" will it start recording your question in order for Google Assistant to fulfill your request. You can always delete all your recordings via \"My activity\" settings under your Google Account.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SX87QAG"},"Title":"HK CITATION: Programmable Presets","Id":"ka21Y000000SX87QAG","ArticleNumber":"000010831","Question__c":"How to create and add Presets","Answer__c":"In our latest update for Citation, we added a couple of new features.
We are going to talk about our new programmable preset feature.

With this feature, you can add a voice command such as "Turn off the lights in the Bedroom" or "Play my playlist Rock road classic" without using your voice.
Once you have recorded the action, you will see an icon on your Citation display. Tap on this specific recorded command, and the Citation will do all the magic for you!

Enough of what it can do, let us create a preset:\n
  1. Scroll down on your Citation Display to you see "Voice presets."
  2. Press on the + sign.
  3. Say your command: Play Radio FM\n\t
    1. Do not use "Hey or OK, Google at this point."
    \n\t
  4. Press the "V" icon after the command is finished.
  5. Select an icon.
  6. Your Preset is now ready, tap it to give it a try.
\nTo delete any presets.\n\n
  • Press and hold down the preset.
  • A menu will appear, hit the "TRASHCAN" icon.
","ArticleType":"How_Tos__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SWIOQA4"},"Title":"HK CITATION: Removing Towers from Surround setup","Id":"ka21Y000000SWIOQA4","ArticleNumber":"000009669","Question__c":"How to remove Citation Towers from a Surround setup and reinstalling them again?","Answer__c":"Perform a factory reset on the Citation Tower speakers by pressing and holding the reset button on the back panel for 5 seconds.\r\nAfter the reset you can now select \"Music\" to set up the Tower speakers to your WiFi network.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVM8QAO"},"Title":"HK Citation: BAR not responding to voice","Id":"ka21Y000000SVM8QAO","ArticleNumber":"000008784","Question__c":"I am using AUX-in, Optical, or HDMI with my Citation Bar, and Google Voice Assistant does not respond. How can I use Google Voice Assistant?","Answer__c":"Use the Google Voice Assistant button on your Citation Bar remote control when using these inputs HDMI, AUX or Optical. When you press this button, the current volume level will temporarily decrease and the Google Voice Assistant will begin listening for your command. \r\nThe reason you need to use the remote control is that Google Assistant does not support Multi-channel audio from your source device (TV, BlueRay Player or TV-BOX) and therefore the mic is automatically muted unless the Google Voice Assistant button is pressed.\r\nThis may be different in the future with new software updates.\r\n\r\nGoogle Voice Assistant is always listening when streaming music over Wi-Fi or Bluetooth.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SVLzQAO"},"Title":"HK Citation: 4 Amber LEDS","Id":"ka21Y000000SVLzQAO","ArticleNumber":"000008757","Question__c":"The 4 LED dots change to amber on my Citation speaker. What does this mean?","Answer__c":"The amber LED lights indicate that the microphone is muted and the Google Assistant will not react to any voice keywords until the microphone is unmuted.","ArticleType":"FAQ__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka21Y000000SXL9QAO"},"Title":"HK CITATION: Frequency response for speakers","Id":"ka21Y000000SXL9QAO","ArticleNumber":"000010972","Question__c":"What is the Frequency response of the Citation series?","Answer__c":"The Frequency response for the Citation series is 20Hz to 20Khz.","ArticleType":"How_Tos__kav"}]}
