Beautiful Sound That Speaks To You
The Harman Kardon Citation Adapt is the next generation wireless digital AV receiver for movies and music. Easy to use with its full-color LCD touch screen, Citation Adapt blends innovation in home audio with attention to detail in design, allowing for sophisticated looks and fully wireless stereo sound when paired with Citation Tower or Citation Sub. Music lovers will love access to over 300 music services and high-definition streaming through Chromecast built-in, while movie lovers enjoy their all wireless home theater system with Citation Adapt as the centerpiece.
Item#
HKCITAADAPTGRYAM
General Specifications
Power supply
100-240v ~ 50/60Hz
Wireless network
802.11a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range
2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power
<20dBm
2.4G Wi-Fi modulation
DBPSK, DQPSK, CCK, QPSK,BPSK,16QAM,64QAM
5G WISA transmitter power
<14dBm
5G WISA modulation
OFDM, BPSK, QPSK, 16QAM
5G WISA transmitter frequency range
5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
Power consumption in sleep mode
<2.0Watts
Note
CITATION ADAPT is intended to be used for streaming music. A consumer can stream Bluetooth audio to the speaker. A consumer can connect their speaker to the localWi-Fi Network and stream music with Google Chromecast. In addition, the speaker will work with Google Home. This product is designed to be instantly on and ready to play music at a moment's notice, therefore, the Bluetooth andWi-Fi connection must remain active at all times to ensure proper operation. CITATION ADAPT is in compliance with the European Union energy legislation. CITATION ADAPT will enter into sleep mode (networked standby) after 20 minutes without operation, after which it can be re-activated via Bluetooth or Wi-Fi.
Dimensions
Dimensions (W x H x D)
305 x 55 x 155mm (12" x 2.2" x 6.1")
Weight
1kg (0.46lb)
Control and Connection Specifications
Bluetooth version
4.2
Bluetooth transmitter power
<10dBm
Bluetooth transmitter modulation
GFSK,π/4 DQPSK, 8DPSK
Bluetooth transmitter frequency range
2402 – 2480MHz
- 1 x Citation Adapt
- 1 x Quick-start guide
- 1 x Warranty sheet
- 1 x Safety sheet
- 1 x power cable (1.8m)

The latest owner's manuals, quick start guides, and documents.
